Intel Solid-State Drive 530

(information from Intel)

image image

Product Specifications:

Model Name Intel® Solid-State Drive 530 Series
Capacity(GB) M.2– 80, 120, 180, 360;
MSATA – 80, 120, 180, 240;
2.5” – 80, 120, 180, 240, 360, 480
NAND Flash Memory 20nm Intel® NAND Flash Memory Multi-Level Cell (MLC)
Bandwidth Form Factor Sequential Read (up to) Sequential Write (up to) Random 4KB Write (TYP) Random Read (up to) Random Write (up to)
M.2 80GB, 120GB, 180GB, 360GB 540 MB/s 490 MB/s   41K IOPs 80K IOPs
mSATA 80GB, 120GB, 180GB, 240GB 540 MB/s 490 MB/s   41K IOPs 80K IOPs
2.5” 80GB 540 MB/s 480 MB/s 33K IOPs 24K IOPs 80K IOPs
120GB 540 MB/s 480 MB/s 37.5K IOPs 24K IOPs 80K IOPs
180GB, 240GB 540 MB/s 490 MB/s 49K IOPs 41K IOPs 80K IOPs
360GB 540 MB/s 490 MB/s 33K IOPs 45K IOPs 80K IOPs
480GB 540 MB/s 490 MB/s 33K IOPs 48K IOPs 80K IOPs
Interface SATA 6Gb/s, compatible with SATA 3Gb/s
Form Factor, Height and Weight Form Factor Height/Weight
M.2 (80mm) Up to 3.7mm / up to 10 grams
mSATA Up to 3.8mm / up to 10 grams
2.5” Up to 7mm / up to 78 grams
Life Expectancy 1.2 million hours Mean Time Between Failures (MTBF)
Minimum Useful Life/Endurance Rating The SSD will have a minimum useful life based on a typical client workload assuming up to 20 GB of host writes per day (5 years)
Power Consumption  Form Factor Active: Idle: DevSleep:
M.2 140 mW Typical 55 mW Typical  200μW
mSATA 140 mW Typical 55 mW Typical  200μW
2.5” 195 mW Typical 125 mW Typical 5mW
Operating Temperature 0° C to 70° C
RoHS Compliance Meets the requirements of European Union (EU) RoHS Compliance Directives
