Panasonic
 Specifications:
 Links of KY-C223B Induction Cooker
 Download of KY-C223B Induction Cooker

Panasonic

(information from Panasonic)

Total Power Consumption (max.): 2.8 kW (13A)

Independent rear, front IH Heater Power Consumption (max.): 2.0 kW
Built-In or Tabletop Design
9 level power control
Count-down timer: 1 min to 99 mins
Auto shutdown function:
- No pot detection or no operation (around 1 min.)
- No operation after heating (around 2 hours)
Overhear prevention, small object detection & pot detection
Wide Burner pitch can heat two large pots simultaneously side-by-side
Child lock
Touch panel & LED display
SCHOTT CERAN® glass
Grade 3 Energy Label
Colour:black
Dimensions (approx.): (W x D x H): 290x520x80mm
Cut-Hole Dimensions: (WxD): 268 x 500 mm
Made in China
5 years warranty^

Specifications:

Model No.KY_C223B Induction Cooker Top Plate Color Black Power RequirementSingle phase 220 V, 50 HZ / 13 A ; 2.0 kW (rear); 2.0kW (front) Dimensions (WxDxH) Approx.290 x520 x80 mm*2 Weight (Approx.)6.3 kg Length of the power cord (approx.)1.2 m Radiant Heater Adjustment- Air Intake and Discharge System- Accessory- IH Maximum HeatingApprox. 2,800 W Heat Adjustment9 level power control Count Down 1-99 mins Count up timer ● Top Plate MaterialSCHOTT CERAN®glass Cooking Ring - Top Plate OperationTouch panel High-Temperature Caution Light ● Remarks^Complete the warranty registration within 30 days from the date of purchase to enjoy 5 years warranty services. Registration webpage
*1 If IH heaters are turned on simultaneously:
- The maximum power of the IH heaters will be adjusted automatically so as to keep the total power unchanged
- Heat level of the IH heater will go down when the other IH heater is used
- Heat level cannot be increased
*2 Exhaust vent cover is included in depth. Fixing template is not included in height
Specifications are subject to change without prior notice.
