    Silent Pro Hybrid 850W

 coolerMaster Website
 Links of Silent Pro Hybrid 850W

Silent Pro Hybrid 850W

(information from Cooler Master )

Specifications:

Model	RS-850-SPHA-D3
Type	Intel ATX 12V V2.3 & SSI EPS 12V V2.92
Dimension	150 x 180 x 86 mm (W x L x H) 5.9 x 7 x 3.4 inch
Input Voltage	90-264V (Auto Range)
Input Current	9-4.5A
Input Frequency Range	60-50Hz
PFC	Active PFC (>0.9)
Power Good Signal	100-500ms
Hold Up Time	17ms
Efficiency	90% Typically
MTBF	100,000 Hours
Protection	OVP / UVP / OCP / OPP / OTP / SCP
Output Capacity	850W
Operation Temperature	0~40XC (Nominal Input Voltage)
Regulatory	TUV / GOST / CE / C-Tick / UL / BSMI / CCC / FCC / KCC
Fan	135mm (Silent Hydraulic Bearings)
Certifications	80 Plus Gold
Connector	M / B 24 pins x 1 CPU 4 + 4 pins x 2 PCI-e 6+2 pins x 6 SATA x 12 Peripheral 4 pins x 5 Floppy 4 pins x 1 Fan cable 3 pins x 3
Output	+3.3V	+5V	+12V	-12V	+5Vsb	+7V
	22A	25A	70A	0.3A	3A	1.8A
Total Power	150W		840W	3.6W	15W	12.6W
	850W
