GX Gold 1050 V2 Full Modular
 Specifications
 coolerMaster Website
 Links of GX Gold 1050 V2 Full Modular

GX Gold 1050 V2 Full Modular

(information from Cooler Master )

Specifications

GX Gold 1050 V2 Full Modular

ModelMPE-A501-AFCAG ATX VersionATX 12V V2.52 PFCActive PFC Input Voltage90-264V Input Current13-6A Input Frequency47-63Hz Dimensions (L x W x H)180 x 150 x 86 mm Fan Size140mm Fan BearingFDB Fan Speed2200 RPM Noise Level @ 20%0 dBA Noise Level @ 50%14.9 dBA Noise Level @ 100%27.3 dBA Efficiency90% @ Typical Load 80 PLUS Rating80 PLUS Gold ErP 2014 Lot 3Yes Operating Temperature0-50°C Power Good Signal100 - 150 ms Hold Up Time>20ms at 100% Load MTBF>100,000 Hours ProtectionsOVP, UVP, OPP, OTP, SCP, OCP RegulatoryTUV, cTUVus, CE, BSMI, FCC, CCC, EAC, RCM, KCC, CB ATX 24-Pin Connectors1 EPS 4+4 Pin Connectors1 EPS 8 Pin Connector1 SATA Connectors12 Peripheral 4-Pin Connectors4 PCI-e 6+2 Pin Connectors6 SeriesGX Series 80 PlusGold ModularFull Modular WattageAbove 750W

coolerMaster Website

Cooler Master - Make It Yours. http://www.coolermaster.com/~~last updated 16 Jul 2017~~

Links of GX Gold 1050 V2 Full Modular

GX Gold 1050 V2 Full Modular 80 Plus Gold Certified ATX Power Supply | Cooler Master https://www.coolermaster.com/catalog/power-supplies/gx-series/gx-gold-1050-v2-full-modular/~~last updated 08 Dec 2021~~
GX Gold 1050 V2 Full Modular 80 Plus Gold Certified ATX Power Supply | Cooler Master https://www.coolermaster.com/catalog/power-supplies/gx-series/gx-gold-1050-v2-full-modular/#specifications~~last updated 08 Dec 2021~~
